Epoch Batteries 12v - 120ah Marine Cranking Duel Purpose Battery
Epoch Batteries 12v - 120ah Marine Cranking Duel Purpose Battery
Couldn't load pickup availability
This is the 12.8v - 120ah Duel Purpose (cranking & reserve) Marine Battery by EPOCH BATTERIES.
COMPANY PROFILE
ADDRESS: 164 Andrew Dr. - Stockbridge, GA 30281
Website: www.epochbatteries.com
BATTERY FEATURES
BLUETOOTH: Yes
MOBILE APPLICATION: Yes
CAN COMMUNICATION: Yes
OWNER'S MANUAL: No
SELF HEATING: Yes
INTEGRATION WITH OEM DISPLAY CLUSTERS: NA
COMPATIBLE WITH THE VEHICLE'S ONBOARD CHARGING SYSTEM: To properly charge your Epoch Batteries, you will want to verify that any charging component in your system is capable of being programmed for the following specifications. Charging components can include, but are not limited to converters, inverter chargers, solar charge controllers, DC to DC chargers, etc.
- Bulk/Absorption: 14.2V – 14.6V
- Absorption Time: Two batteries in parallel connections require 30 minutes 200Ah
- Float: 13.4V – 13.8V
- Equalization: 14.4V/ Disabled
- Temperature Compensation: 0/Disabled
- Charge Rate: 50% of the battery or battery bank capacity
- Battery Charge Temperature Range: 32°F (0°C) to 131°F (55°C)
- Battery Discharge Temperature Range: -4°F (-20°C) to 140°F (60°C)
- Cell Charge Temperature: 32°F (0°C) to 131°F (55°C)
NOTE: Not all chargers are capable of multistage charging. If yours is not, you will want to verify it can be programmed for the Bulk/Absorption voltage and have the other items mentioned disabled if applicable. Consult your charger's manual or the manufacturer.
BATTERY SPECIFICATIONS
VOLTAGE: 12.8v
AMP HOUR RATING: 120ah
ENERGY: 1,536 Wh
CELL TYPE: LiFeP04
CONNECTIVITY: (4) series | (16) parallel
PEAK DISCHARGE CURRENT: 800a (10s) - 600a (10s)
CONTINUOUS DISCHARGE CURRENT: 150a
COLD CRANKING AMPS: 1100 CCA (Compatible with all outboard motors up to 250hp)
RECOMMENDED DISCHARGE TEMPERATURE RANGE: -4 to 140F
CHARGING TEMPERATURE RANGE: 34F - 140F
DIMENSIONS: (LxWxH) 12.125" x 6.61" x 8.31"
WEIGHT: 27.56 lb
CASE TYPE: Plastic Shell
ENCLOSURE RATING: IP67
TERMINAL TYPE: M8 / 8-12 N.m
SELF DISCHARGE: 3% / Mo.
DATA SHEET LINK: www.epochbatteries.com
TECHNICAL SUPPORT
By phone Mon-Fri - 9am-5pm EST. - Schedule tech support online
www.epochbatteries.com/support
WARRANTY
11 YEAR WARRANTY (3 years at 100% & 9 years prorated)
LINK: www.eposchbatteries.com/warranty
INSTALLATION VIDEOS
- Coming Soon
